2022 John Deere Gator XUV835M

Your Price: $15,399

77 people have recently viewed it.
Check Availability Hi, my name is and I'm interested in this 2022 John Deere Gator XUV835M Base . I'm in the area and you can reach me at or on my phone at .




  • Status:
    Pre-Owned
  • Vehicle:
    2022 John Deere Gator XUV835M
  • Model Number:
    57K0M
  • Location:
    Midland Powersports
  • Warranty:
    As Is

BRAKES

  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc

DRIVE LINE

  • Differential Lock Location:
    Front / Rear
  • Driveline Brand:
    On-Demand™
  • Driveline Type:
    4X4
  • Number Of Driveline Modes:
    2
  • Rear Unlocking Differential:
    Yes

ENGINE

  • Bore (in):
    2.83
  • Bore (mm):
    72
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    9.5
  • Cooling:
    Liquid
  • Cylinders:
    3
  • Displacement (cc):
    812
  • Displacement (ci):
    49.5
  • Engine Brand Name:
    Chery
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    In-Line
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Regular
  • Fuel Type:
    Gas
  • Horsepower (bhp):
    54
  • Horsepower (kW):
    43
  • Horsepower RPM:
    6000
  • Starter:
    Electric
  • Stroke (in):
    2.62
  • Stroke (mm):
    66.5
  • Torque (Ft Lbs):
    47
  • Torque (Nm):
    64
  • Torque RPM:
    3200
  • Valve Configuration:
    DOHC
  • Valves Per Cylinder:
    4
  • Valves:
    12

EXTERIOR

  • A-Arm Skid Plate (Front):
    Yes
  • A-Arm Skid Plate (Rear):
    Yes
  • Bash Plate (Front):
    Yes
  • Bash Plate (Rear):
    Yes
  • Body Material:
    Plastic
  • Brush Guard:
    Yes
  • Cab Door Material:
    Soft
  • CV Boot Cover:
    Yes
  • Drive Shaft Skid Plate:
    Yes
  • Frame:
    Steel
  • Front Mud Guards:
    Yes
  • Full Length Skid Plate:
    Yes
  • Light Guard:
    Yes
  • Rear Mud Guards:
    Yes

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge
  • Temperature Warning Type:
    Light

LIGHTS

  • Type:
    Halogen

SEATS

  • Folding:
    Yes
  • Number Of Rows:
    1
  • Number Of Seats:
    3
  • Seat Material:
    Vinyl
  • Seat Type:
    Bench

STEERING

  • Steering Control:
    Steering Wheel
  • Steering Type:
    Power

STORAGE

  • Bed Capacity (kgs.):
    454
  • Bed Capacity (lbs.):
    1000
  • Bed Height (in):
    12
  • Bed Height (mm):
    304.8
  • Bed Length (in):
    45
  • Bed Length (mm):
    1143
  • Bed Volume (ft3):
    16.4
  • Bed Volume (m3):
    0.46
  • Bed Width (in):
    52
  • Bed Width (mm):
    1320
  • Cargo Bed Material:
    Steel
  • Cargo Bed Tilt:
    Yes
  • Integral Tie-Down Hooks:
    Yes
  • Number Of Cupholders:
    4

SUSPENSION

  • Front Stabilizer Bar:
    Yes
  • Front Suspension Type:
    Independent Double A-Arm
  • Front Travel (in):
    7.9
  • Front Travel (mm):
    200.7
  • Number Rear Shock Absorbers:
    2
  • Rear Stabilizer Bar:
    Yes
  • Rear Suspension Type:
    Independent Double A-Arm
  • Rear Travel (in):
    9.1
  • Rear Travel (mm):
    231.14

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    823
  • Dry Weight (lbs):
    1810
  • Front Tread Width (in):
    52.8
  • Front Tread Width (mm):
    1341
  • Fuel Capacity (gal):
    11.2
  • Fuel Capacity (l):
    42.4
  • Ground Clearance (in):
    11.2
  • Ground Clearance (mm):
    284
  • Height (in):
    78
  • Height (mm):
    1981
  • Length (ft):
    10.58
  • Length (ft/ft):
    10
  • Length (ft/in):
    7
  • Length (in):
    127
  • Length (mm):
    3228
  • Payload Capacity (kgs):
    677
  • Payload Capacity (lbs):
    1493
  • Rear Tread Width (in):
    49.6
  • Rear Tread Width (mm):
    1259
  • Towing Capacity (kgs):
    907
  • Towing Capacity (lbs):
    2000
  • Wet Weight (kg):
    868
  • Wet Weight (lbs):
    1913
  • Wheelbase (in):
    84.5
  • Wheelbase (mm):
    2146
  • Width (in):
    63.7
  • Width (mm):
    1618

TOWING & HAULING

  • Front Hitch Type:
    Receiver
  • Rear Hitch Type:
    Receiver
  • Size (cm):
    5.1
  • Size (in):
    2

TRANSMISSION

  • Hi / Low Range:
    Yes
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Transmission Type:
    Continuously Variable (CVT)

WHEELS & TIRES

  • Front Tire (Full Spec):
    Terrahawk AT
  • Front Tire Diameter (in):
    25
  • Front Tire Width:
    9
  • Front Wheel Diameter:
    12
  • Rear Tire (Full Spec):
    Terrahawk AT
  • Rear Tire Diameter (in):
    25
  • Rear Tire Width:
    11
  • Rear Wheel Diameter:
    12
  • Tire Brand:
    Terrahawk
  • Tread Type:
    All Terrain
  • Wheels Composition:
    Aluminum
